Stormnet Models can be viewed in 3D CAD. The Visualization tab is used to input parameters for Visualizing the Subcatchment in 3D CAD

Table below is a list of the parameters:

Field Description
Height Height of the subcatchment in (ft or meter)
Centroid X: Centroid's x coordinate
Centroid Y: Centroid's y coordinate
Elevation Elevation of the subcatchment's Centroid(ft or m).
Top Image: Image for the Top of the subcatchment
Side Image: Image for the side of the subcatchment



Note: The centroid's coordinates and elevation are calculated by Stormnet during the Add DEM process (go to menu item Simulate --> Add DEM)
